Kab rov tav Machining Center

Kab rov tav Machining Center

HWM 110
HMC CNC Kab rov tav CNC Tshuab Center

HWM 110

HMC CNC Kab rov tav CNC Tshuab Center

HORIZONTAL CNC MACHIING CENTER (HMC)

Yam khoom	Chav tsev	HWM 110
Mus ncig
X Axis Travel	mm	2500
Y Axis Travel	mm	1200
Z Axis Ncig Tebchaws	mm	1300
Spindle
Spd. Center rau Rooj	mm	150-1350
Spd.Nose rau Table Center	mm	350-1650
Spindle Taper		ISO 50
Spindle Ceev	RPM	6000
Spindle Tsav	KW	PAB 22/26
Spindle Max. Torque	N.m	560/800
Ratary Worktable (B Axis)
Worktable (LxW)	mm	1100x1100
Min. Qib	Deg	1 degree /0.001 degree
Basis Hole Dia.	mm	Φ50H7
Max.Loading	KG	2500
Faib qhov tseeb	sec	15 degree
Rov ua qhov tseeb	sec	± 4 degree
Worktable No.		2
Feedrate
Rapid Feedrate	m/min	24/24/24
Txiav Feedrate	hli/min	1-7000
ATC
ATC No.	T	40/60
Qhov tseeb
Positioning raug	mm	±0.008
Rov ua qhov tseeb	mm	±0.005
Lwm tus
Cua Siab	Kgf/c㎡	6
Tshuab hnyav	KG	27000
Hneev taw	mm	5650x5450
Tshuab Qhov siab	mm	4470

Standard Parts:

1. Spindle Driver system (xws li Spindle Motor, Spindle, Pulley thiab lwm yam)

2. Peb axis servo system (Servo motor, Linear guideway, Ballscrew thiab lwm yam)

3. Cov qauv tseem ceeb Qhov chaw (xws li tshuab txaj, worktable, machinecolumn, kem puag, spindle box thiab lwm yam.)

4. CNC maub los (nrog rau lub thawv ua haujlwm, hluav taws xob txee, phau ntawv tes wheeland thiab lwm yam.)

5. 10.4 nti muaj yeeb yuj saib

6. Ntsuas qhov system (Sib npaug lub tog raj kheej, Hydraulic chaw nres tsheb, siab siab yeeb nkab thiab lwm yam.)

7. Cua Circuit Court system (xws li FR & L, electromagnetic valve thiab lwm yam)

8. Tsis siv neeg lubrication system

9. Txiav kua system

10. Transformer thiab hluav taws xob lub thawv kub exchanger

11. Cov cuab yeej hloov khoom siv

12. Cov cuab yeej ua kom txias txias (Spindle coolant thaum txiav)

13. Lub teeb ua haujlwm, peb lub teeb xim

14. RS - 232 kis tau tus mob interface

15. X, Y, Z axis hauv kev tiv thaiv npog

16. Leval hloov qhov system

17. Cov ntaub ntawv tshuab
