Taw qhia

Raws li cov cuab yeej siv tau zoo, Plano CNC miller tuaj yeem tsis tsuas yog ua cov txheej txheem ua tiav los ntawm kev ua kom tiav, tab sis kuj tuaj yeem ua tiav ntau cov txheej txheem xws li milling, drilling, tapping, thiab tho txawv. Cov cuab yeej tau nruab nrog lub siab zoo spindle los muab ntau yam kev sib hloov ceev, thiab nws kuj muaj Taiwanese pob ntsia hlau thiab xauv txiv ntoo kom ua tiav qhov chaw ntawm cov khoom kom ntseeg tau qhov siab tshaj plaws qhov tseeb thiab txo qis wobble. Ua tsaug rau kev teeb tsa ntawm Japanese NSK bearings thiab German R plus W couplings, cov cuab yeej siv tau zoo thiab tsis tshua muaj suab nrov.

Lub tshuab lubrication tsis siv neeg tuaj yeem muab lubrication rau cov khoom siv, uas tuaj yeem pab cov neeg siv txo qis kev tu thiab tu lub sijhawm. Txhawm rau kom yooj yim ntxiv rau hauv cov ntawv thov, koj tuaj yeem xaiv siv lub nti conveyor kom txo cov khib nyiab pov tseg. Plano CNC miller muaj ib tug tshwj xeeb high-speed linear dov qhia tsim, thiab nws yog dav siv nyob rau hauv kev ua ntawm lub cev qhov chaw, plhaub qhov chaw, thiab disc qhov chaw nyob rau hauv cov tub rog complexes, tsheb, pwm, machinery manufacturing thiab lwm yam lag luam.

Kev teeb tsa:

High quality resin xuab zeb

Taiwan spindle

Taiwan pob ntsia hlau thiab xauv txiv ntoo

Taiwan siab lub tog raj kheej

Japanese NSK bearing lub teb chaws Yelemees R plus W coupling

Tsis siv neeg lubrication system

Chip conveyor ntawm yeem

Khoom Specification

Yam khoom

Chav tsev

YMC-3227A

YMC-4227A

YMC-5227A

YMC-6227A

YMC-3227B

YMC-4227B

Lub rooj ua haujlwm

Worktable Size

mm

3000×2300

4000×2300

5000×2300

6000×2300

3000×2300

4000×2300

Max.Loading ntawm Rooj

KG

12000

16000

18000

20000

15000

20000

T-Qhov

mm

11-22×200

Mus ncig

Gantry Dav

mm

2700

X/Y/Z Travel

mm

3200/2700/1000

4200/2700/1000

5200/2700/1000

6200/2700/1000

3200/2700/1000

4200/2700/1000

Spindle Nose rau Rooj

mm

310-1310

Pub System

CNC maub los

FANUC-0i MF

X/Y/Z Rapid Feed

m/min

12/12/10

10/12/10

8/12/10

12/12/10

10/12/10

Txiav Feed

m/min

7

ATC/Tool Magazine (Rau Center)

Tool Capacity

BT50/32

Max.Tool Dia./Length

mm

Φ125/300

Tool Hloov Txoj Kev

Pneumatic

Max.Tool Nyhav

KG

18

Qhov tseeb

Positioning raug

mm

±0.008/300

Re-Positioning raug

mm

±0.005/300

Spindle

Spindle Ceev

rpm ua

4000

Spindle Model thiab Dia.

BT50

Spindle Tsav

KW

15/18.5

Cua Siab

Huab cua yuav tsum

kg/c ㎡

Ntau dua lossis sib npaug 6

Cua Presuure Flux Rate

m³/min

Ntau dua lossis sib npaug rau 0.5

Tshuab Loj

Tshuab hnyav

KG

41000

46000

51000

53000

43000

47000

Tshuab Footprint

mm

7840×5150×4850

9840×5150×4850

11840×5150×4850

13840×5150×4850

7840×5150×4850

9840×5150×4850
