CNC Tapping thiab Drilling Center

3 axis, 4 axis, 5 axis CNC drilling thiab Tapping center

TC-540/TC-640/TC-750/TC{3}}



Khoom Taw Qhia

CNC Tapping thiab Drilling Center yog cov cuab yeej tshuaj ntsuam xyuas siv nyob rau hauv kev ua haujlwm ntawm kev siv tshuab. Nws yog cov cuab yeej siv tshuab uas txhim kho kev tsim khoom kom muaj txiaj ntsig ntau dua hauv kev ua cov khoom lag luam thiab cov khoom siv hauv ntau yam xws li tsheb, ob-log maus taus, thiab cov khoom siv IT. Nws tsis tsuas yog ua rau tapping ua, txawm tias milling tshuab ua thiab precision drilling ua tau, thiab txawm nce mus txog qib siab dua ntawm kev tsim khoom, kev ua haujlwm, thiab kev ntseeg tau.



Yam khoom	Chav tsev	TXC -540	TXC -640	TXC -750	TXC -1000
Lub rooj ua haujlwm
Worktable Size	mm	650×400	700×420	900×420	1100×500
Max.Loading ntawm Rooj	KG	250	250	300	400
T-Qhov	mm	3-14×125	3-14×125	3-14×125	3-14×125
Mus ncig
XYZ Travel	mm	500×400×300	600×400×300	700×500×330	1000×500×330
Spindle Nose rau Rooj	mm	150-450	150-450	150-480	150-480
Pub System
CNC maub los		FANUC-0i MF	FANUC-0i MF	FANUC-0i MF	FANUC-0i MF
XYZ Rapid Feed	m/min	48	48	48	48
Txiav Feed	m/min	10	10	10	10
ATC/Tool Magazine
Tool Capacity		14/16/21T	14/16/21T	14/16/21T	14/16/21T
Max.Tool Nyhav	KG	3	3	3	3
Max.Tool Dia.	mm	⌀80	⌀80	⌀80	⌀80
Max.Tool Length	mm	250	250	250	250
Tool Xaiv Txoj Kev		Random	Random	Random	Random
Qhov tseeb
Positioning raug	mm	±0.008/300	±0.008/300	±0.008/300	±0.008/300
Re-Positioning raug	mm	±0.005/300	±0.005/300	±0.005/300	±0.005/300
Spindle
Spindle Ceev	rpm ua	12000 (15000 / 20000 Opt.)	12000 (15000 / 20000 Opt.)	12000 (15000 / 20000 Opt.)	12000 (15000 / 20000 Opt.)
Spindle Taper		BT30	BT30	BT30	BT30
Spindle Tsav	KW	3.75/5.5	3.75/5.5	3.75/5.5	3.75/5.5
Lub zog xav tau	KVA	15	15	25	25
Tshuab Loj
Tshuab Footprint	mm	2200×1600	2300×1800	2400×2200	2700×2200
Tshuab Qhov siab	mm	2900	3000	3200	3200
Tshuab hnyav	KG	3000	3800	5200	6200





Lub ntsiab nta

Xws li cnc tapping center muaj cov nram qab no nta:

1. lub hauv paus, kem, lub ntsiab spindle lub thawv, hla zawv zawg rooj, worktable thiab lwm qhov chaw tau tsim nrog lub zog siab casting tshuab.

2. lub puab metallographic qauv yog ruaj khov heev.

3. cov casting qhov chaw qhia rational geometry muaj pes tsawg leeg los ntawm tshuab cuab tam kinetics thiab finite element tsom xam.

4. cov hauv paus ntsiab lus muaj siab steel xwm los ntawm collocating nrog lub reinforcing tav.

5. nrog lub hauv paus dav, lub thawv-zoo li kab noj hniav, broaden & lengthening zawv zawg hauv paus thiab siab heev tsim ntawm mechanics ntawm cov ntaub ntawv, lub peev xwm yuav tsum tau guaranteed.

6. Kev kub ceev thiab siab precision spindle, max. tuaj yeem yog 24000rpm:

7. CE Standard thiab CE Certificate;



Peb Qhov Kev Pabcuam

Kev teeb tsa:

Tus neeg muag khoom yuav tsum xa ib tug engineer mus rau lub buyer lub teb chaws rau installation, commissioning thiab kev cob qhia. Tus neeg yuav khoom yog lub luag haujlwm los muab txhua yam khoom tsim nyog rau kev tuav thiab nqa lub tshuab ua ntej tus neeg muag khoom engineers mus rau tus neeg yuav khoom cog. Tsis tas li ntawd, tus neeg yuav khoom yuav tsum muab cov neeg ua haujlwm txhawb nqa hauv kev teeb tsa kev ua ub no, nyob rau hauv kev saib xyuas los ntawm tus muag khoom engineers.



Commission:

Tus neeg muag khoom yuav tsum muab cov duab kos thiab lwm cov ntsiab lus ntawm cov khoom siv / kev npaj yuav tsum tau rau kev teeb tsa cov tshuab uas tus neeg yuav khoom yuav tsum tau npaj thiab npaj ua ntej lub tshuab tuaj txog ntawm tus neeg yuav khoom lub Hoobkas. Kev teeb tsa thiab commissioning tuaj yeem ua tiav hauv 10-15 hnub rau saum tshuab feem ntau.
